Wet Drum Magnetic Separator

At MagSmith Magnetics Industry, we are a leading manufacturer of industrial magnets in Pakistan. We specialize in designing and manufacturing tailored-made magnetic solutions for various industries. Our product range includes:
  • 10000+ Gauss Rods
  • Grill Magnetic Separators
  • Drum Magnetic Separators
  • High Intensity Plate Separators

Wet Drum Magnetic Separator

Magsmith Magnetic Industry’s Wet Drum Magnetic Separator is designed to remove very fine magnetizable components from low concentration, low viscosity liquids.



Working Principle

The liquid flows through a semicircular separating chamber beneath a stainless steel drum. The cylinder consisting of permanent magnetic discs are positioned within the drum to which the magnetizable particles are attracted. By rotating the drum, the filter cake is lifted out of the slurry and the magnetic field.



Applications

These magnetic separators are commonly used in various industries, including:

  • Metal processing industry

  • Treatment of pre-concentrates extracted from high gradient magnetic filter

  • Dense media plants

  • Iron ore processing

  • Recycling and waste management

Features and Benefits

Wet Drum Magnetic Separator offer several features and benefits, including:

  • High efficiency in separating magnetizable components

  • Increases product purity and plant productivity

  • Removes contaminants from the product stream

  • Suitable for low concentration, low viscosity liquids

  • Durable and corrosion-resistant construction

  • Semicircular separating chamber for efficient separation

  • Permanent magnetic discs for strong magnetic field

  • Stainless steel drum for durability and corrosion resistance

How it Works

Here’s a step-by-step explanation of how a Wet Drum Magnetic Separator works:

Step 1: Feed Material
 A mixture of water and magnetic particles (such as iron ore, magnetite, or ferrosilicon) is fed into the separator.

Step 2: Drum Rotation
 The drum, which is partially submerged in the feed material, rotates at a slow speed

Step 3: Magnetic Field
 A strong magnetic field is generated by the permanent magnetic discs or electromagnets located inside the drum.

Step 4: Magnetic Separation
 As the drum rotates, the magnetic field attracts and holds the magnetic particles, separating them from the non-magnetic particles.

Step 5: Non-Magnetic Discharge
 The non-magnetic particles, now free from magnetic particles, are discharged from the separator as a clean product.

Step 6: Magnetic Collection
 The magnetic particles, still attached to the drum, are collected and discharged as a separate product.

Step 7: Drum Cleaning
The drum is continuously cleaned by the water flow, which helps to remove any accumulated magnetic particles and maintain the separator’s efficiency.

The Wet Drum Magnetic Separator is an efficient and effective way to separate magnetic particles from non-magnetic particles in a wet environment.

Our Clients

Our products are trusted by big Pakistani companies like:

Why Choose MagSmith Magnetics Industry?

At MagSmith Magnetic Industry, we are committed to providing high-quality Wet Drum Magnetic Separator that meet the specific needs of our customers. We have a proven track record of delivering efficient and reliable magnetic separation solutions.

Our company will provide  permanent (lifetime) after sales service
